Schüco Windows

Windows allow you to see from the inside of a building through to the outside. They ensure the right amount of natural light while also providing sufficient privacy. The design of the window is therefore just as important as its function. Be it for a newbuild or a renovation, Schüco windows are available in a wide range of basic depths and opening types and with practical comfort components. Find the perfect window for every application – from barrier-free and sound reduction right through to panorama windows with the most slimline face widths.

Antimicrobial coating for window handles and profiles

Hygiene requirements continue to rise, especially in areas such as hospitals, nursing homes, nurseries and public buildings. This applies in particular to multi-resistant germs that no longer respond to treatment with conventional medication. Schüco is responding by developing the first window system with an antimicrobial surface finish for window handles. Schüco SmartActive can be used flexibly on the window system depending on requirements – either on the handles only, as the primary contact surfaces, or for the inside of the entire room as well. And it is guaranteed to be free from nano particles.

Windows - Product List

Schüco Window System AWS 75 BS.HI+


Min. face width	67 mm
Uf value of frame (≥)	1.6 W/(m²·K)
Max. glass/panel thickness	52 mm
Max. vent width	1500 mm
Max. vent height	2200 mm
Max. sound reduction index Rwp	49 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC3
Wind load resistance	Class C5 / B5
CE marking	Yes

Schüco Window System AWS 65 BS


Min. face width	67 mm
Uf value of frame (≥)	1.9 W/(m²·K)
Max. glass/panel thickness	34 mm
Max. vent width	1500 mm
Max. vent height	2200 mm
Max. sound reduction index Rwp	47 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC3
Wind load resistance	C5/B5
CE marking	Yes

Schüco Window System AW 40.NI


Min. face width	74 mm
Max. glass/panel thickness	26 mm
Max. vent width	1500 mm
Max. vent height	2400 mm
Air permeability	Class 4
Watertightness	Class 9A
CE marking	No

Schüco Window System AWS 50.NI


Min. face width	84 mm
Max. glass/panel thickness	42 mm
Max. vent width	1700 mm
Max. vent height	2500 mm
Max. sound reduction index Rwp	43 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC 1
Wind load resistance	Class C5 / B5
CE marking	Yes

Schüco Window System AWS 50


Min. face width	91 mm
Uf value of frame (≥)	2.5 W/(m²·K)
Max. glass/panel thickness	40 mm
Max. vent width	1700 mm
Max. vent height	2500 mm
Max. sound reduction index Rwp	43 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC 1
Wind load resistance	Class C5 / B5
CE marking	Yes

Schüco Window System AWS 60


Min. face width	91 mm
Uf value of frame (≥)	1.7 W/(m²·K)
Max. glass/panel thickness	50 mm
Max. vent width	1700 mm
Max. vent height	2500 mm
Max. sound reduction index Rwp	47 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC 2
Wind load resistance	Class C5 / B5
CE marking	Yes

Schüco Window System AWS 65


Min. face width	91 mm
Uf value of frame (≥)	1.9 W/(m²·K)
Max. glass/panel thickness	55 mm
Max. vent width	1700 mm
Max. vent height	2500 mm
Max. sound reduction index Rwp	47 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC3
Wind load resistance	Class C5 / B5
CE marking	Yes

Schüco Window System AWS 70.HI


Min. face width	91 mm
Uf value of frame (≥)	1.5 W/(m²·K)
Max. glass/panel thickness	62 mm
Max. vent width	1700 mm
Max. vent height	2500 mm
Max. sound reduction index Rwp	48 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC3
Wind load resistance	Class C5 / B5
CE marking	Yes

Schüco Window System AWS 75.SI+


Min. face width	91 mm
Uf value of frame (≥)	0.92 W/(m²·K)
Max. glass/panel thickness	61 mm
Max. vent width	1700 mm
Max. vent height	2500 mm
Max. sound reduction index Rwp	48 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC3
Wind load resistance	Class C5 / B5
CE marking	Yes

Schüco Window System AWS 75 PD.SI


Min. face width	55 mm
Uf value of frame (≥)	1.7 W/(m²·K)
Max. glass/panel thickness	50 mm
Max. vent width	1450 mm
Max. vent height	2500 mm
Max. sound reduction index Rwp	46 dB(A)
Air permeability	Class 4
Watertightness	Class 9A
Burglar resistance	Up to RC 2
Wind load resistance	Class C5 / B5
CE marking	Yes
